Features
Micro-electronic keyboard control operation interface, versatile, easy to operate.
Pneumatic components using world-renowned brands, powerful, durable.
Workbench and network arm fine-tuning function, the version quickly and easily.
Gear rack synchronous transmission structure, with the mold, to ensure accurate positioning printing.
Equipped with special shock absorber, printing performance is superior and stable.
Widely used in a variety of cups, bottles, tubes, cans and other cylindrical, round
Cone and elliptical surface silk screen operations.
Technical Parameters
|
Mechanical model
|
WSC-360C
|
|
Maximum size of web frame:
|
350X550mm
|
|
Maximum printing area:
|
110/200X345mm
|
|
Printing speed:
|
1300 cycle/hour
|
|
Electric power:
|
110V or 220V 50/60HZ 20W
|
|
Dimensions:
|
870X760X1360mm
|
|
net weight:
|
175KG
|
Application areas
Widely used in graphic or flat parts for surface printing patterns such as: cups, electronic products, cosmetics bottles, joints, pen, toys, mineral water bottles, shampoo bottles.
Seat the surface of the rack racks! Using the world famous brand pneumatic components drive, advanced IC screen printing machine, smooth operation, easy adjustment, a security device, printing speed and adjustable travel, easy to operate and so on.
