WSC-350BR/4
Features
The characteristics of flat screen printer.
Screen plate up/down, light and compact.
Microcomputer control, multi-function, easy operation.
World-famous pneumatic components power, durable and solid
Worktable and screen arm micro adjustable, easy commissioning ,gear and rack convey cooperatively with a suitable fixture, precise printing positioning ,special shock absorber ,stable performance, mesh clean and replace is convenient with printing head up device (some types) avoid mesh sticking after printing with screen plate up device (some type)It can be widely applied in the industry of textile printing ,electronics, arts, decoration, publishing, and so on.
Technical Parameters

Mechanical model

WSC-350BR/4

Max.screen plate size

300X400mm

Max.printing area

120X200mm

Printing thickness

80mm

Printing speed

1200 cycle/hour

Wortable size



Power SPEC

110V or 220V 50/60HZ

Power consumption

800W

Dimensions

1050X810X1680mm

Net weight

240KG

Typical Application areas
Cars: motormeter, tank, window glass.
Electronic products: keypad, silicon keys, phone window, membrane key, circuit board.
Electronic appliances: nameplate, dial scale, fireplace glass, appliance housing ,glass.
Ads: postal, dossal ,label, road marker, meal card, credit card.
Customs: T-shirt, flag, knit goods.
Gift: Toys, stationery, handicraft, transfer paper.

Application areas

Machines of this series can be widely applied to print on various kinds of key –press electric components like computer, mobile phone. electric panel. telephone, game player, etc, Machine is also suitable to print on accessories of hardware or plastics like logo ,toy, and commodity. Special design is available according to customer’s specific requirements.
