Features
The characteristics of curve screen printer.
Microcomputer control, multi-fucntion, easy operation ,world famous pneumatic components power, durable and solid, worktable and screen arm micro adjustable ,easy commissioning ;gear and rack convery cooperatively with a suitable fixture, precise printing positioning ;special shock absorber, stable performance, widely apply to print various kinds of curve surfaces of columnar, oval cup, bottle ,tube, can.
Technical Parameters

Mechanical model	WSC-500
Max.screen plate size	400X700mm
Max.printing area	150/250X470mm
Printing thickness	200m
Printing speed	1000 cycle/hour
working desk size	350X550mm
Power SPEC	110V or 220V 50/60HZ
power consumption	20W
Dimensions	1060X1100X1680mm
Net weight	210KG

Typical application

Widely apply in various kinds of cup, bottle ,tube ,buckle, and cans.

Application Areas

Machines of this series can be widely applied to print on various kinds of key –press electric components like computer, mobile phone. electric panel. telephone, game player, etc, Machine is also suitable to print on accessories of hardware or plastics like logo ,toy, and commodity. Special design is available according to customer’s specific requirements
