Location  Home -> Products  ->  Pad Printer  ->  Single Color Inkwell  ->  WN-122X
WN-122X
Features
The characteristics of single-color inkwell pad printer.
Machine of this series adopts single-color inkwell ,using oil supply system.
Microelectronic keyboard operation controller(PIC control).
Independent pad up/down stroke and speed adjustable.
Worktable is adjustable in X.Y.Z and angle directions.
with a wide range of applications. high printing efficiency ,easy operation .they can be widely applied to print on electronic products ,home appliances ,hardware, plastics, toys and stationery, etc, satisfying various printing requirement (flat, curve, irregular surface printing). Widely used in electronics, electrical appliances, hardware, plastics, toys, stationery and other industries.
Technical Parameters

Model

WN-122X

Single cycle:

YES

Max.print(h)

220mm

Cycle/hour

1600Pcs/h

Cliche size

100mmx100mm

Printing area

60mmX60mm

Control panel

TOUCHscreen

Power supply

110V or 220V 50/60Hz

Electric power

20W 6Bar

External dimensions:

770mmX580mmX1400mm

Application areas
Machines of this series can be widely applied to print on various kinds of key –press electric components like computer, mobile phone. electric panel. telephone, game player, etc, Machine is also suitable to print on accessories of hardware or plastics like logo ,toy, and commodity. Special design is available according to customer’s specific requirements.
Ink mode:
Ink well type can be applied in big size printing and easy to install and operate. The operation is more flexible ,you can directly printing after ink adjusted.
Model
