Features
The characteristics of single-color ink cup printer.
Machine of this series adopts single –color ink-saving inkcup, using oil supply system.
Microelectronic keyboard operation controller(PIC control).
Independent pad up/down stroke and speed adjustable.
Worktable is adjustable in X.Y.Z and angle directions.
with a wide range of applications. high printing efficiency ,easy operation .they can be widely applied to print on electronic products ,home appliances ,hardware, plastics, toys and stationery, etc, satisfying various printing requirement (flat, curve, irregular surface printing).
Technical Parameters

Model	WN-122FE
Single cycle:	YES
InkCup:	Φ60 MM
Max.print(h)	280mm
Cycle/hour	600Pcs/h
Cliche size	50mmx280mm
Printing area	ø75mm
Control panel	TOUCHscreen
Power supply	110V or 220V 50/60Hz
Electric power	20W 6Bar
External dimensions	770mmX820mmX1400mm

Application areas
Machines of this series can be widely applied to print on various kinds of key –press electric components like computer, mobile phone. electric panel. telephone, game player, etc, Machine is also suitable to print on accessories of hardware or plastics like logo ,toy, and commodity. Special design is available according to customer’s specific requirements.

Ink mode:
Adopts imported ceramic ring,sealed ink cup can maximally reduce ink waste and the evaporation of the smell.ink can be stored in the cup for a long duration with stable viscosity.it’s famous for being economic and environment-friendly.
