WN-121XE
Features
The characteristics of single-color ink cup printer.
Machine of this series adopts single –color ink-saving inkcup, using oil supply system.
Microelectronic keyboard operation controller(PIC control).
Independent pad up/down stroke and speed adjustable.
Worktable is adjustable in X.Y.Z and angle directions.
with a wide range of applications. high printing efficiency ,easy operation .they can be widely applied to print on electronic products ,home appliances ,hardware, plastics, toys and stationery, etc, satisfying various printing requirement (flat, curve, irregular surface printing).
Technical Parameters

Model

WN-121XE

Single cycle

YES

InkCup

Φ60 MM

Max.print(h)

200mm

Cycle/hour

1800Pcs/h

Cliche size

75mmx150mm

Printing area

ø50mm

Control panel:

TOUCHscreen

Power supply:

110V or 220V 50/60Hz

Electric power:

20W 6Bar

External dimensions:

590mmX480mmX1240mm

Ink mode:
Adopts imported ceramic ring,sealed ink cup can maximally reduce ink waste and the evaporation of the smell.ink can be stored in the cup for a long duration with stable viscosity.it’s famous for being economic and environment-friendly.
